High quality - made in Taiwan.
FOR CUTTING
Steel, Non-ferrous, Plastics, Wood
FEATURES
> Fixed bow
> All ball-bearing blade guides
> All cast-iron frame and bed
> Swivel head mitre cut to 45°
> Manual or automatic down feed operation
> Adjustable hydraulic cylinder for automatic feed option
> Wide blade minimises run-out for more accurate cutting
> Can replace the function of traditional cold-cut saws, but with greater capacity
> Supplied on Machine Stand with integrated coolant system
SPECIFICATIONS
Motor 1.5 kW 3Ph 2-speed
Blade size 3215 x 27 x 0.9 mm
Blade speed 29, 50, 73, 95 m/min
Bow Swivel 0 - 45 degree
Dimension 1820 x 780 x 1340 mm
Weight Nett/Gross 340 / 440 kg
CAPACITY
At 90 degrees
Solid round 254mm diameter
Solid square 254 x 254mm
Solid rectangle 406 x 160mm
At 45 degrees
Solid round 170mm diameter
Solid square 170 x 170mm
Solid rectangle 190 x 160mm
NOTES
> Use Lactuca cutting oil for best efficiency and cut quality.
