FOR CUTTING
Steel, Non-ferrous, Plastics, Wood
FEATURES
> Fixed bow
> Automatic down feed stop
> All ball-bearing blade guides
> All cast-iron frame and bed
> Hydraulic down feed control with infinitely variable adjustment
> Wheels allow easy movement around the workshop
> 3-speed belt drive allows machine to handle a wide range of materials
SPECIFICATIONS
Single-phase motor 1.1kW
Blade size 2655mm x 27mm x 0.9mm
Blade speed 26, 50, 73, 95 m/min
Bow Swivel Fixed Bow
Dimension 1540 x 590 x 1150 mm
Weight Nett/Gross 230 / 260 kg
CAPACITY
At 90 degrees
Solid round 230mm diameter
Solid rectangle 305 x 178mm
At 45 degrees
Solid round 150mm diameter
Solid rectangle 150 x 127mm
NOTES
> Use Lactuca cutting oil for best efficiency and cut quality.
