IMPORTANT SHIPPING CRITERIA FOR THIS ITEM
This item is over 25Kg so it must be sent by Transport (i.e. collected and delivered by truck). The standard delivery charge calculated at checkout only covers delivery to town and city CBD business addresses (and if applicable the local freight depot). Unfortunately, it does not cover working from home business addresses. If you are unsure if your address qualifies for the standard shipping rate or want to have this item delivered to a home or rural address please contact us for a quote before ordering.
FEATURES
Load limited
Emergency Stop
Thermal Overload Protection
Grade 80 alloy steel load chain
Pressed steel structure
High tensile alloy steel top bottom hooks
Light weight compact design combined with high efficiency motor
Limit switches top and bottom to prevent chain runout
Complies with ASNZS1418.2 standard
SPECIFICATIONS
Capacity 2 Ton
2 Speed
3 phase 415V 50Hz
Motor power 3.0/1.0kW
Lifting height 6m
Lifting speed 6.8/2.3 m/min
No of chain 1
Chain link dia. 10mm
Running test load: 25 kN
Extra Weight per metre of extra lift: 2.3 kg
IP Rating: hoist IP54 / control IP65
Weight 115 kg
Extension chain available separately by the metre, contact us for a quote.
