IMPORTANT SHIPPING CRITERIA FOR THIS ITEM
This item is over 25Kg so it must be sent by Transport (i.e. collected and delivered by truck). The standard delivery charge calculated at checkout only covers delivery to town and city CBD business addresses (and if applicable the local freight depot). Unfortunately, it does not cover working from home business addresses. If you are unsure if your address qualifies for the standard shipping rate or want to have this item delivered to a home or rural address please contact us for a quote before ordering.
FEATURES
2-speed operation
Load limited with thermal overload prevention
Pressed steel structure, high strength body
High tensile alloy steel top and bottom hooks
Grade 80 - 7.1mm alloy steel load chain
Light weight compact design combined with high efficiency
Limit switches fitted at top and bottom ends to prevent chain runout
SPECIFICATIONS
Capacity 1 Ton
Lifting height 3m
Dual speed
Single phase 230V 1200 W
Running test load 12.5 kN
Motor power 1.2 kW
No of chain 1
Chain link dia. 7.1 mm
Lifting speed 6 m/min
Extra weight per m of extra lift 1.1 kg
Weight 60 kg
Extension chain available separately by the metre, contact us for a quote.
